Microsoft Dynamics 365 App for Outlook is an Office add-in that you can quickly add to your user’s outlook applications.

So they can track emails and appointments, create contacts, and review Dynamics 365 information in context of their emails or their appointments.

To be eligible for this app, Users will need the Use Dynamics 365 App for Outlook privilege and have server -side synchronization set up for incoming emails or for appointments, Contacts and Tasks.

Microsoft Dynamics 365 App for Outlook uses relevance search. If relevance search is turned on for your organization, make sure that these entity types are searchable: Account, Opportunity, Case, Contact, Lead.

How to enable relevance search in Dynamics 365:

Go to the system settings and set up search then enable the relevance search.

Advantages of the Relevance search:
Relevance Search brings the following enhancements and benefits:

Improves performance with external indexing and Azure Search technology.
Finds matches to any word in the search term in any field in the entity.
Matches may include inflectional words, like “stream”, “streaming”, or “streamed”.
Returns results from all searchable entities in a single list sorted by relevance,
based on factors like number of words matched or their proximity to each other in the text.
Matches in the result list are highlighted.

Note
Relevance Search isn’t available for Dynamics 365 (on-premises) organizations.

Relevance Search is disabled by default. Your administrator needs to enable it for the organization. After Relevance Search is enabled,
you may have to wait up to an hour or more, depending on the size of your organization,
before you start seeing the Relevance Search results in the Dynamics 365 web application.
Smaller changes in indexed data may take up to 15 minutes to show up in your system.

While Relevance Search finds matches to any word in the search term in any field in an entity,
 in Quick Find, even with the full-text search enabled, all words from the search term must be found in one field.

In Relevance Search, the better the match, the higher it appears in the results.
A match has a higher relevancy if more words from the search term are found in close proximity to each other.
The smaller the text where the search words are found, the higher the relevancy.
For example, if you find the search words in a company name and address, it may be a better match than the same words found in a large article,
far apart from each other. Because the results are returned in a single list, you may see a mix of records displayed one after another, such as accounts,
opportunities, leads, and so on.
 The matched words in the list are highlighted.

I hope this helps.

• What is the Gantt diagram?
• How to make a Gantt chart in Excel
• Excel Gantt chart templates

What is a Gantt chart?

The Gantt chart bears a name of Henry Gantt, American mechanical engineer and management consultant who invented this chart as early as in 1910s. A Gantt diagram in Excel represents projects or tasks in the form of cascading horizontal bar charts. A Gantt chart illustrates the breakdown structure of the project by showing the start and finish dates as well as various relationships between project activities, and in this way helps you track the tasks against their scheduled time or predefined milestones.

How to make Gantt chart in Excel 2010, 2007 and 2013

1. Create a project table

Tip. Only the Start date and Duration columns are really necessary for creating an Excel Gantt chart. However, if you enter the End Dates too, you can use a simple formula to calculate Duration, as you can see in the screenshot below.

2. Make a standard Excel Bar chart based on Start date

• Select a range of your Start Dates with the column header, it’s B1:B11 in our case. Be sure to select only the cells with data, and not the entire column.
• Switch to the Insert tab > Charts group and click Bar.
• Under the 2-D Bar section, click Stacked Bar.

As a result, you will have the following Stacked bar added to your worksheet:

Step 3. Add Duration data to the chart

1. Right-click anywhere within the chart area and choose Select Data from the context menu.

   The Select Data Source window will open. As you can see in the screenshot below, Start Dateis already added under Legend Entries (Series). And you need to add Duration there as well.
2. Click the Add button to select more data (Duration) you want to plot in the Gantt chart.

3. The Edit Series window opens and you do the following:
   • In the Series name field, type “Duration” or any other name of your choosing. Alternatively, you can place the mouse cursor into this field and click the column header in your spreadsheet, the clicked header will be added as the Series name for the Gantt chart.
   • Click the range selection icon  next to the Series Values field.

4. A small Edit Series window will open. Select your project Duration data by clicking on the first Duration cell (D2 in our case) and dragging the mouse down to the last duration (D11). Make sure you have not mistakenly included the header or any empty cell.

5. Click the Collapse Dialog icon to exit this small window. This will bring you back to the previous Edit Series window with Series name and Series values filled in, where you click OK.

6. Now you are back at the Select Data Source window with both Start Date and Duration added under Legend Entries (Series). Simply click OK for the Duration data to be added to your Excel chart.

   The resulting bar chart should look similar to this:


Step 4. Add task descriptions to the Gantt chart

1. Right-click anywhere within the chart plot area (the area with blue and orange bars) and click Select Data to bring up the Select Data Source window again.
2. Make sure the Start Date is selected on the left pane and click the Edit button on the right pane, under Horizontal (Category) Axis Labels.

3. A small Axis Label window opens and you select your tasks in the same fashion as you selected Durations in the previous step – click the range selection icon , then click on the first task in your table and drag the mouse down to the last task. Remember, the column header should not be included. When done, exit the window by clicking on the range selection icon again.

4. Click OK twice to close the open windows.
5. Remove the chart labels block by right-clicking it and selecting Delete from the context menu.

   At this point your Gantt chart should have task descriptions on the left side and look something like this:


Step 5. Transform the bar graph into the Excel Gantt chart

1. Click on any blue bar in your Gantt chart to select them all, right-click and choose Format Data Series from the context menu.

2. The Format Data Series window will show up and you do the following:
   • Switch to the Fill tab and select No Fill.
   • Go to the Border Color tab and select No Line.

   Note. You do not need to close the dialog because you will use it again in the next step.
3. As you have probably noticed, the tasks on your Excel Gantt chart are listed in reverse order. And now we are going to fix this.
   Click on the list of tasks in the left-hand part of your Gantt chart to select them. This will display the Format Axis dialog for you. Select the Categories in reverse order option under Axis Options and then click the Close button to save all the changes.

   The results of the changes you have just made are:
   • Your tasks are arranged in a proper order on a Gantt chart.
   • Date markers are moved from the bottom to the top of the graph.
   Your Excel chart is starting to look like a normal Gantt chart, isn’t it? For example, my Gantt diagram looks like this now:


Step 6. Improve the design of your Excel Gantt chart

1. Remove the empty space on the left side of the Gantt chart.
   As you remember, originally the starting date blue bars resided at the start of your Excel Gantt diagram. Now you can remove that blank white space to bring your tasks a little closer to the left vertical axis.
   • Right-click on the first Start Date in your data table, select Format Cells > General. Write down the number that you see – this is a numeric representation of the date, in my case 41730. As you probably know, Excel stores dates as numbers based on the number of days since 1-Jan-1900. Click Cancel because you don’t actually want to make any changes here.

   • Click on any date above the task bars in your Gantt chart. One click will select all the dates, you right click them and choose Format Axis from the context menu.

   • Under Axis Options, change Minimum to Fixed and type the number you recorded in the previous step.
2. Adjust the number of dates on your Gantt chart.
   In the same Format Axis window that you used in the previous step, change Major unit and Minor unit to Fixed too, and then add the numbers you want for the date intervals. Typically, the shorter your project’s timeframe is, the smaller numbers you use. For example, if you want to show every other date, enter 2 in the Major unit. You can see my settings in the screenshot below.
   Note.In Excel 2013 and Excel 2016, are no Auto and Fixed radio buttons, so you simply type the number in the box.

   Tip. You can play with different settings until you get the result that works best for you. Don’t be afraid to do something wrong because you can always revert to the default settings by switching back to Auto in Excel 2010 and 2007, or click Reset in Excel 2013.
3. Remove excess white space between the bars.
   Compacting the task bars will make your Gantt graph look even better.
   • Click any of the orange bars to get them all selected, right click and select Format Data Series.
   • In the Format Data Series dialog, set Separated to 100% and Gap Width to 0% (or close to 0%).

   And here is the result of our efforts – a simple but nice-looking Excel Gantt chart:

   Remember, though your Excel chart simulates a Gantt diagram very closely, it still keeps the main features of a standard Excel chart:
   • Your Excel Gantt chart will resize when you add or remove tasks.
   • You can change a Start date or Duration, the chart will reflect the changes and adjust automatically.
   • You can save your Excel Gantt chart as an image or convert to HTML and publish online.
   Tips:
   • You can design your Excel Gant chart in different ways by changing the fill color, border color, shadow and even applying the 3-D format. All these options are available in the Format Data Series window (right-click the bars in the chart area and select Format Data Series from the context menu).

   • When you have created an awesome design, it might be a good idea to save your Excel Gantt chart as a template for future use. To do this, click the chart, switch to the Design tab on the ribbon and click Save as Template.

Excel Gantt chart templates

Gantt chart template for Excel 2013 from Microsoft

In Excel 2013, this template is available directly on the File > New tab. If you cannot find it there, you can download it from Microsoft’s web-site – Gantt Project Planner template. This template requires no learning curve at all, simply click on it and it’s ready for use.

Online Gantt chart template

The process is very straightforward, you enter your project details in the left-hand table, and as you type a Gantt Chart is being built in the right-hand part of the screen.

Gantt chart template for Excel, Google Sheets and OpenOffice Calc

Gantt chart template from vertex42.com is a free Gantt chart template that works with Excel 2003, 2007, 2010 and 2013 as well as OpenOffice Calc and Google Sheets. You work with this template in the same fashion as you do with any normal Excel spreadsheet. Simply enter the start date and duration for each task and define % in the Complete column. To change the range of dates displayed in the Gantt chart area, slide the scroll bar.
